We provide Sonic drill (SD) and Super Probe (SP).

The introduction of renewable energy attracts attention as a key role of future energy policy. Especially, among renewable energies, the promotion under various measures for power generating and enery-saving businesses utilizing Geothermal Energy which exists richly to enable a stable supply or unerground thermal energy with low temperature is enhanced. We can provide the equipment that enables a safety and efficient operation for constructing the exploration and production well of Geothermal Energy and Underground Thermal Energy, or underground heat exchange well.

Product introduction

Application Series
of Model		 Size Model Name
Utilization of Ground Thermal Energy SD Large
Type		 SD-100 SD-125 SD-150T SD-160 SD-175
SD-200A SD-250A 　 　 　
Large
Type		 SDH-100 　 　 　 　
SP Large
Type		 SP-8000 SP-50 　 　 　
Utilization of Geothermal Energy HLL Large
Type		 HLL-Special HLL-Standard HLL-SUPER 　 　
TSL Large Type TSL-1 TSL-HD 　 　 　

※ Model with pale colored letters is not utilized in this application.

TOA-TONE BORING CO.,LTD.
TOA-TONE BORING CO.,LTD.

Underground Thermal Energy

Outdoor temperature varies throughout the year but underground temperature shows a stable temperature (around 17℃). Utilization of Underground Thermal Energy actualizes energy-saving air-conditioning using temperature gradient between outdoor and underground temperature.

Large capacity drill (SD)　Rotary and vibration

SD (Sonic Drill) has an innovative drilling technology providing the rotation and vibration with drill bit. Compared with conventional rotary method, DTH hammer method or rotary percussion method, remarkable high speed drilling is realized. This technology is introduced under license from Sonic Drill, Canada and recently shows its high performance for the heat supply business (regional air-conditioning) around Tokyo Sky Tree area

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation
Speed		 Rotating
Torque		 Tilting
Angle		 Feed
Force		 Balance
Force		 Stroke
Length
SD-100 9.0 t

0-60min-1

Rotation, forward：3.9kN･m
Rotation, reverse：4.4kN･m 		0-35° 48.5kN 48.5kN 3850mm
SD-125 10.0t

0-57min-1
0-114min-1

Rotation, forward：2.9kN･m
5.8kN･m
Rotation, reverse：Same as forward 		0-45° 68.6kN 68.6kN 4630mm
SD-150T 12.5 t

0-105min-1

Rotation, forward：4.9kN･m
Rotation, reverse：5.9kN･m 		0-90° 78.5kN 78.5kN 4850mm
SD-160 12.5 t

0-100min-1

Rotation, forward：4.9kN･m
Rotation, reverse：5.9kN･m 		0-45° 78.6kN 78.6kN 4850mm
SD-175 12.0 t

0-105min-1

Rotation, forward：4.9kN･m
Rotation, reverse：5.9kN･m 		0-45° 98.0kN 98.0kN 4450mm
SD-200A 16.5 t

0-100min-1

Rotation, forward：6.4kN･m
Rotation, reverse：7.8kN･m 		0-90° 137.2kN 137.2kN 4450mm
SD-250A 16.5 t

0-100min-1

Rotation, forward：6.4kN･m
Rotation, reverse：7.8kN･m 		0-90° 98.0kN 137.2kN 4450mm

Features

  • A variety of drilling capability for the most ground formations by means of unique vibration mechanism
  • Actualization of remarkable high speed drilling
  • Drilling without use of circulation fluid
  • Easy collection of samples
  • Low noise and vibration drill being friednly to neighboring environment
  • Superior accuracy of hole verticality

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
SD-200A

≪Tokyo Sky Tree≫
Photo by the courtesy of
Tobu Energy Management Co., Ltd.

TOA-TONE BORING CO.,LTD.
SD-175
TOA-TONE BORING CO.,LTD.
SD-250A
TOA-TONE BORING CO.,LTD.
SD-100

Large size drill (SP)　Rotary and vibration

SP (Super Probe) has a same drilling technolgy as Sonic Drill, providing the rotation and vibration with drill bit. Super Probe is a next generation drill which is developed on our own and is more compact than Sonic Drill to be operatable at restricted small space.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill
Head		 Feed
System
Rotation
Speed		 Rotating
Torque		 Feed
Force		 Balance
Force		 Stroke
Length
SP-8000 5.5 t
（7.3t：O.P）

Low
：0-27min-1
：0-33min-1（O.P）

Low
：5.4kN･m
46.0kN 98.0kN 1800mm
3000mm
（O.P）

High
：0-54.2min-1
：0-105min-1（O.P）
（At without use of vibration）

High
：2.7kN･m

Features

  • Drilling capability for sand, gravel and boulder layer by means of unique vibration mechanism
  • Unique low noise and vibration mechanism being friednly to neighboring environment
  • High drilling performance despite its compact design
  • Foldable leadler during transportation and mobilization
  • Optional tilting mechanism of drill head
  • Optional longer mast to handle 2.0 m long drill rod

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
SP-8000
TOA-TONE BORING CO.,LTD.
SP-8000
TOA-TONE BORING CO.,LTD.
SP-8000

Geothermal Energy

Geothermal power generation is carried out by rotating the turbine with high temperature steam heated by magma and gushed from deep underground, and enables to generate the power stably without any influences of weather, season, day and night.

Large drills (HLL)　Drive Head

HLL-Standard and HLL-Special drills are ultra deep hole drilling machine developed for geothermal exploration. These drills are drive head type drills which have been developed world-first. Succeeded drill of these drills is TSL series universal type drill equipped with rotary table. These drills are selectable from the requirement of rotation speed, rotating torque and hoisting capacity and are utilized for Hot Spring Development with the depth requirement of around 2000 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Spindle Rotation Speed Feed System
Feed
Force		 Balance
Force		 Stroke
Length
HLL-Standard 6.5t Type
（A）

Rotation, forward：20、50、150min-1
Rotation, reverse：12、19min-1

156.9kN 215.7kN 1430mm
Type
（B）

Rotation, forward：40、100、300min-1
Rotation, reverse：24、38min-1

Type
（C）

Rotation, forward：80、200、600min-1
Rotation, reverse：48、76min-1

HLL-Special 8.4t

Rotation, forward：60、120、400min-1
Rotation, reverse：36、72、240min-1

245.2kN 323.6kN 1070mm

Features

  • Applicable to ultra deep hole drilling
  • Equipped with drive head featuring low speed and high torque

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
HLL-Standard

Large capacity drill（TSL）　Universal

TSL-1 and TSL-HD drills have been developed as ultra deep hole drilling machines for the geothermal exploration and production wells. These drills are universal type drills equipped with both of drive head and rotary table. By moving drive head, both of wireline core drilling and non-core drilling is carried out by one machine. Drill is selectable from the requirement of hositing capacity, rotation speed and rotating torque, and is also used for developing hot spring well with depth requirement of around 1,000 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Rotation Speed Hoisting
Capacity		 Stroke
Length
Drive Head Rotary Table
TSL-1 11.0ｔ

Rotation, forward：
60、125、265、420min-1

Rotation, forward：
30、62、132、210min-1
9.0ｔ 750mm

Rotation, reverse：
36、75、160、255min-1

　
TSL-HD 13.0ｔ

Rotation, forward：
47、97、206、327min-1

Rotation, forward：
24、48、103、164min-1
12.0ｔ 750mm

Rotation, reverse：
28、58、124、198min-1

　

Features

  • Universal type drill combined with drive head and rotary table
  • More powerful hoisting capacity for TSL-HD drill
  • Apply to use API (American Petroleum Institute) standard drill pipe and drill collar

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
TSL-1
TOA-TONE BORING CO.,LTD.
TSL-HD
TOA-TONE BORING CO.,LTD.
TSL-HD
