We provide enouogh lineup of equipment for lanslide control work and restraint work.

Japan with a lot of steap mountains is under geographical environment that is apt to cause sediment-related disasters such as landslide and debris flow induced by earthquake, typhoon or heavy rain. There are 520 thousand hazardous palces of sediment-related disaster all over the country and about 1000 sediment-related disasters occur every year throughout the country.
The investigation at the place occurring landslide is carried out by drilling survey and drilling technology is also applied as the countermeasure of Landslide Prevention Work. We can provide the equipment securing the safety and improving operating efficiency for Landslide Prevention Work, meeting the requirement from our customers.

Product introduction

Application	Series of Model	Size	Model Name
Landslide Prevention Work Control Work	TOP	Large Type	TOP-LS21	TOP-MM	TOP-SS
	TOP	Large Type	TOP-100	TOP-150	TOP-300	TOP-750	TOP-750HR
	SD	Large Type	SD-100	SD-125	SD-150T	SD-160	SD-175
			SD-200A	SD-250A
			SDH-100
	HDS	Large Type	HDS-S	HDS-M
	TNS	Large Type	TNS-15
Landslide Prevention Work Preventive Work	LS	Small Type	LS-15
	TBM	Medium Type	TBM-88	TBM-88LH	TBM-88LH150
	HLL	Medium Type	HLL-Super
	LFM	Large Type	LFM-400	LFM-700	LFM-1500
	HDS	Large Type	HDS-S	HDS-M
	TNS	Large Type	TNS-15
	ESD	Small Type	ESD40Ⅱ	ESD150

※ Model with pale colored letters is not utilized in this application.

Control Work

In order to drain the groundwater inducing landslide, horizontal drilling method by drilling horizontally from ground surface to drain the groundwater, or water collecting method by drilling horizontally from large diameter (3.5 m) water well is applied.

Large size drill（TOP）　Horizontal drilling

TOP-LS21, TOP-MM and TOP-SS drills are specially designed for horizontal drilling and enable horizontal drilling in fractured formation. The function of drill has dual tube system to rotate outer casing and inner rod simultaneously. Drilling proceeds as inner bit drills inside outer casing and outer bit drills around outer casing by protecting inner rod from the jamming or formation collapse for smooth penetration of inner rod. Model is selectable depend on rotation torque, feed force and balance force meeting the requirement of drilling depth.

These drills are utilized not only for retaining work for landslide prevention, but also for pilot dewatering hole drilling which was applied for "Jouetsu Super Express Railway" and "Seikan Tunnel" projects, Scientific Investigation, horizontal grout hole drilling for ground improvement and the installation work of various size of pipes for water supply and sewage.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle		Feed System
Model Name	Machine Weight	Max. Torque	Rotation Speed	Feed Force	Pull Force	Stroke Length
TOP-LS21	5.5ｔ	Low Speed：19.6 kN・m	Low Speed：7-29 min-1	117.7KN	117.7KN	1800 or 1800×2mm
		2rd：9.5 kN・m	2rd：14-60 min-1
		3rd：4.8 kN・m	3rd：29-118 min-1
		High Speed：2.3 kN・m	High Speed：58-244 min-1
TOP-MM	1.3ｔ	Low Speed：5.9 kN・m	Low Speed：0-30 min-1	58.8KN	58.8KN	1400mm
TOP-MM	1.3ｔ	High Speed：2.9 kN・m	High Speed：0-60 min-1	58.8KN	58.8KN	1400mm
TOP-SS	0.5t	Low Speed：4.9 kN・m	Low Speed：0-30 min-1	29.4KN	29.4KN	1400mm
TOP-SS	0.5t	High Speed：2.5 kN・m	High Speed：0-60 min-1	29.4KN	29.4KN	1400mm

TOA-TONE BORING CO.,LTD.

TOP-LS21

TOP-MM

TOP-SS

Large capacity drill (SD)　Rotary and vibration horizontal drilling

SD (Sonic Drill) has an innovative drilling technology providing the rotation and vibration with drill bit simultaneously and SDH-100 is a high speed drilling machine suitable for short distance drilling up to 100 m. For water collecting work, a sampling work is not possible due to the limited working space inside, but a sampling work for horizontal drilling is possible by equpping special attachment.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Drill Head		Feed System
Model Name	Machine Weight	Rotating Torque	Rotation Speed	Feed Force	Pull Force	Stroke Length
SDH-100	2.2t	Low：4.9ｋN・m High：2.4ｋN・m	Low：0-60min-1 High：0-120min-1	60.8kN	60.8kN	2050mm

Features

Capable of drilling for the most ground formations by means of unique vibration mechanism
Actualization of remarkable high speed drilling
Drilling without use of circulation fluid
Low noise and vibration drill being friednly to neighboring environment

TOA-TONE BORING CO.,LTD.

SDH-100

Large capacity drills (HDS, TNS)　Hydraulic rotary percussion drill

HDS-S, HDS-M and TNS-15 are hydraulic rotary percussion drills suitable for short range drilling up to 100 m, which are designed and manufactured based on the requriement from our customers. These drills have integral structures composed of percussion and rotation unit and have mechanism combined with percussive and cutting demolition. All hydraulically driven system can adjust percussion force and rotation speed infinitely so as to drill for a variety of ground formation. Model can be selected based on the requirement of pulling capacity and stroke length.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Drilling Diameter	Drifter			Feed System
Model Name	Machine Weight	Drilling Diameter	Percussive Force	Rotating Torque	Tilting Angle	Feed Force	Pull Force	Stroke Length
HDS-S	1.8ｔ	96-165mm	0.18-0.49kN	2.9-5.9kN	Up： 0° Down：90°	43.1kN	43.1kN	1400mm
HDS-M	1.9ｔ	96-165mm	0.18-0.49kN	2.9-5.9kN	Up： 0° Down：90°	43.1kN	43.1kN	1950mm
TNS-15	2.7t	96-216mm	0.39-0.64kN	4.1-8.2kN	Up： 7° Down：95°	58.8kN	58.8kN	2800mm

Features

Smooth pulling work of casing by means of damper mechanism
Actualization of highly efficient drilling performance by equipping variable stroke mechanism
High clamping force by all hydraulic centralizer with double cylinder system
Capable of large hole drilling by the use of a large wrench (for TNS-15)
Smooth rod recovery by means of double clamping system (for TNS-15)
Smooth parallel shifting by equipping slide base (for TNS-15)

TOA-TONE BORING CO.,LTD.

HDS-S

HDS-M

TNS-15

Move to top page.

Preventive Work

In oder to stop landslide by adding the resistance against sliding soil block, a method to install a pile into the layer deeper than sliding face, anchoring method giving the resistance by wire tension or shaft work to install a large diameter reinforced concrete pile is applied.

Small capacity drill (LS)　Tilt

LS-15 is an exclusive drill for slope anchoring which is designed and manufactured based on the requirement from our customers. Adjustment of drilling angle can be made arbitrarily and its very compact and light weight design enables smooth transportation and mobilization.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Tiliting Angle	Drill Head		Feed System
Model Name	Machine Weight	Tiliting Angle	Rotating Torque	Rotation Speed	Feed Force	Pull Force	Stroke Length
LS-15	0.26t	Up： 0° Down：90°	Low：1.0ｋN・m Middle：0.7ｋN・m High：0.2ｋN・m	Low：18min-1 Middle：25min-1 High：72min-1	0.015kN	0.015kN	1700mm

TOA-TONE BORING CO.,LTD.

LS-15

Medium capacity dirll (TBM-88)　Spindle

TBM-88 drill is a medium size spindle type drilling machine being designed and manufactured based on the requirement from our customer. This drill is equipped with hydraulic slide base as standard and is a medium size high performance drill regarding the operability as important under various working conditions.This drill is utilized not only for Landslide Prevention Work, but also for drilling hot spring well, water well, monitoring well, mineral exploration, cast-in-place pile, etc. Nominal drilling capacity of this drill for Landslide Prevention Work is approx. 150 meters.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
TBM-88	2.25ｔ	Type （A）	Rotation, forward：30、60、100、145min-1	68.6kN	78.5kN	500mm
		Type （A）	Rotation, reverse：24min-1
		Type （B）	Rotation, forward：50、100、170、240min-1
		Type （B）	Rotation, reverse：40min-1
		Type （C）	Rotation, forward：100、210、350、500min-1
		Type （C）	Rotation, reverse：33min-1

Factory Option

Hydraulic chuck, out rigger, spindle safety cover and platform of TBM-88 drill

TOA-TONE BORING CO.,LTD.

TBM-88

Large capacity drill (HLL)　Large hole diameter drive head

HLL-SUPER is developed for large and deeper hole drilling based on the requirement from our customers. This drill has s high rotating torque and enough feed force and can drill upto 1000 meters with 214 mm hoel diameter. This drill is utilized not only for Landslide Prevention Work, but also for ground water development and geothermal exploration.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed		Feed System
Model Name	Machine Weight	Spindle Rotation Speed		Feed Force	Balance Force	Stroke Length
HLL-SUPER	5.5t	Type （A）	Rotation, forward：15、22、38、58、93、140min-1	156.9kN	215.7kN	750mm
		Type （A）	Rotation, reverse：12、19min-1
		Type （B）	Rotation, forward：30、44、76、116、186、280min-1
		Type （B）	Rotation, reverse：24、38min-1

TOA-TONE BORING CO.,LTD.

HLL･super

Large capacity drill (LFM)　Electrically driven top drive long feed drill

LFM-700 and LFM-1500 are large size electrically driven top drive drills being manufactured based on the requirement from our customers. Compared with hydraulic system, power loss is less and 3 m length hole drilling can be carried out in single continuous operation by DTH hammer method in combination with high rotating torque and long feed stroke. These models have nominal drilling capacity of 400 m and 600 m respectively and are utilized not only for Landslide Prevention Work, but also for steel pipe piling work and ground water development.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Spindle Rotation Speed	Feed System
Model Name	Machine Weight	Spindle Rotation Speed	Feed Force	Balance Force	Stroke Length
LFM-700	5.1t	Rotation, forward：15、26、54、92min-1	41.2kN	94.1kN	4500mm
LFM-1500	6.5t	Rotation, forward：7、14min-1	41.2kN	96.1kN	4500mm

TOA-TONE BORING CO.,LTD.

LFM-700

LFM-1500

Large capacity drills (HDS, TNS)　Hydraulic rotary percussion drill

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Drilling Diameter	Drifter			Feed System
Model Name	Machine Weight	Drilling Diameter	Percussive Force	Rotating Torque	Tilting Angle	Feed Force	Pull Force	Stroke Length
HDS-S	1.8ｔ	96-165mm	0.18-0.49kN	2.9-5.9kN	Up： 0° Down：90°	43.1kN	43.1kN	1400mm
HDS-M	1.9ｔ	96-165mm	0.18-0.49kN	2.9-5.9kN	Up： 0° Down：90°	43.1kN	43.1kN	1950mm
TNS-15	2.7t	96-216mm	0.39-0.64kN	4.1-8.2kN	Up： 7° Down：95°	58.8kN	58.8kN	2800mm

Features

Smooth pulling work of casing by means of damper mechanism
Actualization of highly efficient drilling performance by equipping variable stroke mechanism
High clamping force by all hydraulic centralizer with double cylinder system
Capable of large hole drilling by the use of a large wrench (for TNS-15)
Smooth rod recovery by means of double clamping system (for TNS-15)
Smooth parallel shifting by equipping slide base (for TNS-15)

TOA-TONE BORING CO.,LTD.

HDS-S

HDS-M

TNS-15

Small capacity drills（ESD）　Hydraulic rotary percussion drill

"ESD" is rotary percussion drill mounted spring type drifter. This drill has less input power but more out power than those currently in use and can be moved smoothly at elevated and restricted space for slope protection work.

We can offer the equipment with "Only One" features upon customer's request.

Model Name	Machine Weight	Drilling Diameter	Drifter			Feed System
Model Name	Machine Weight	Drilling Diameter	Percussive Force	Rotating Torque	Tilting Angle	Feed Force	Pull Force	Stroke Length
ESD-40Ⅱ	0.49t	Max 133mm	0.29kN	Low ：2.36kN･m High：1.18kN･m	Up： 0° Down：90°	18.6kN	18.6kN	1580mm
ESD-150	1.62t	Max 133mm	0.59kN	Low ：6.12kN･m High：3.06kN･m	Up： 7° Down：90°	39.4kN	39.4kN	2350mm

ESD40Ⅱ

ESD150
