We provide a lineup of equipment enabling the operation at restricted space safely and securely.

Ground Improvement Work for housing sites is to strengthen the ground bearing strength to prevent the irregular sinking of constructed residential houses due to the cause of too soft ground or partially soft ground to support such houses. To resolve housing defects, the Housing Quality Assurance Act and the Law for Execution of Warranty against Housing Defects was enforced in 2000 and in 2009 respectively, however, the damage of houses by the incidence of liquefaction caused by the Great East Japan Earthquake in 2011 was seriously come up and the importance of ground improvement for housing was much enhanced. We can provide the equipment with a better mobility and operability, that can operate safely and efficiently for Ground Improvement Work.

Product introduction

Application Series
of Model		 Size Model Name
Housing Ground Improvement Work GT Medium Type GT-750 GT-1000S GT-1300
Large Type GT-1000LH GT-2000LH 　

Medium capacity drill (GT)

GT-750, GT-1000S and GT-1300 are medium size ground improvement drills forming soil-cement column by mixing and kneading the cement milk with soil that is loosend cylindrically by kneading blade installed on the low end of drill rod. These drills have the mechanism seriously considering the mobility and operability at restricted space and have various line-up of rotating torque, feed speed and compactness. These drills are utilized not only for housing ground improvement, but also for soft soil improvement.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
GT-750 4.0t

Low：0-25min-1
Middle：0-50min-1
High：0-100min-1

Low：3.5kN・m
Middle：3.7kN・m
High：1.8kN・m

24.5kN 24.5kN 2300mm
GT-1000S 6.5t

Low：0-20min-1
Middle：0-40min-1
High：0-80min-1

Low：9.8kN・m
Middle：4.9kN・m
High：2.5kN・m

24.5kN 24.5kN 3500mm
GT-1300 7.0t

Low：0-23min-1
Middle：0-45min-1
High：0-90min-1

Low：13.1kN・m
Middle：6.6kN・m
High：3.3kN・m

43.2ｋN 43.2kN 5500mm

Factory Option

  • Equipped with sub hoist driven by hydraulic motor
  • Equipped with earth-moving blade and hoisiting appratus

Features

  • 3 step adjustable rotation speed of rotary head
  • Light total weight from 4.0 ton to 7.0 ton
  • Available to equip with operation control device of various manufacturers
  • Most compact size with the width of 1550 mm (for GT-750 and GT-1000S)
  • High rotating torque of 9.7 kN-m despite compact size (for GT-1000S)
  • Biggest torque among "GT" series drills (for GT-1300S)

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
GT-750
TOA-TONE BORING CO.,LTD.
GT-1000S
TOA-TONE BORING CO.,LTD.
GT-1000S
TOA-TONE BORING CO.,LTD.
GT-1300

Large capacity drill (GT)

GT-1000LH drill and GT-2000LH drill are a large size ground improvement drill forming soil-cement column by mixing and kneading the cement milk with soil that is loosend cylindrically by kneading blade installed on the low end of drill rod. These drills have a mechanism seriously considering the stability at restricted space and has a longest feed stroke of 6 m among "GT" series drills. These drills are utilized not only for housing ground improvement, but also for soft soil improvement.

We can offer the equipment with "Only One" features upon customer's request.

Model
Name		 Machine
Weight		 Drill Head Feed System
Rotation Speed Rotating Torque Feed
Force		 Balance
Force		 Stroke
Length
GT-1000LH 4.0t

Low：0-21min-1
Middle：0-42min-1
High：0-85min-1

Low：9.8kN・m
Middle：4.9kN・m
High：2.5kN・m

24.5kN 24.5kN 6000mm
GT-2000LH 12.9t

Low：0-11min-1
Middle：0-45min-1
High：0-90min-1

Low：19.6kN・m
Middle：4.9kN・m
High：2.5kN・m

29.4kN 29.4kN 6000mm

Factory Option

  • Equipped with sub hoist driven by hydraulic motor
  • Equipped with earth-moving blade and hoisting appratus

Features

  • 3 step adjustable rotation speed of rotary head
  • Longest feed stroke of 6000 mm among "GT" series drills
  • Available to equip with operation control device of various manufacturers
  • Good mechanical stability by deviding water swivel and rotary head individually

TOA-TONE BORING CO.,LTD.

TOA-TONE BORING CO.,LTD.
GT-1000LH
